PERFECT cable gland 50.6xx M
Dome nut Brass CuZn39Pb3, nickel-plated
Lamellar insert Polyamide PA6 V-2
Sealing ring Polychloroprene-Nitrile rubber CR/NBR
Gland body Brass CuZn39Pb3, nickel-plated
O-ring Nitrile rubber NBR
Connecting thread metric, as per EN 60423
Properties
• integrated anchorage
• protection against twisting
• wide sealing and clamping
range
• easy-to-install
Temperature range -20 °C / +100 °C (dynamic)
-40 °C (static, short term)
Protection grade IP68
5 bar / IP69K*
Test standard EN 62444
UL 514B
VDE licence 40020901
DNV GL Certificate TAE0000386
UL / CSA-File E140310
Comment details about test results - see annex
Features
Connecting thread standard length
A ØC L SW1 SW2 H
VPE
Part No.
M12x1,5 3 - 6 5 14 14 25 100 50.612 M
M16x1,5 5 - 9 5 17 17 30 100 50.616 M
M20x1,5 9 - 13 6 22 22 33,5 100 50.620 M
M25x1,5 11 - 16 7 27 27 36,5 50 50.625 M
M32x1,5 14 - 20 8 34 34 38 25 50.632 M
M40x1,5 19 - 27 8 43 43 41 10 50.640 M
M50x1,5 24 - 35 9 55 55 49,5 5 50.650 M
Jacob GmbH ∙ Elektrotechnische Fabrik ∙ Gottlieb-Daimler-Straße 11 ∙ 71394 Kernen ∙ Telefon 07151 4011-0 ∙ Fax 07151 4011-49 ∙ E-Mail: jacob@jacob-gmbh.de
Jacob
A ØC L SW1 SW2 H
VPE
Part No.
M63x1,5 32 - 42 10 65 65 52,5 5 50.663 M
M63x1,5 38 - 48 10 65 65 52,5 5 50.663 M1
Connecting thread long
A ØC L SW1 SW2 H
VPE
Part No.
M12x1,5 3 - 6 10 14 14 30 100 50.612 M-L
M16x1,5 5 - 9 10 17 17 35 100 50.616 M-L
M20x1,5 9 - 13 10 22 22 37,5 100 50.620 M-L
M25x1,5 11 - 16 11 27 27 40,5 50 50.625 M-L
M32x1,5 14 - 20 13 34 34 43 25 50.632 M-L
M40x1,5 19 - 27 13 43 43 46 10 50.640 M-L
M50x1,5 24 - 35 14 55 55 54,5 5 50.650 M-L
M63x1,5 32 - 42 14 65 65 56,5 5 50.663 M-L
M63x1,5 38 - 48 14 65 65 56,5 5 50.663 M1/L
with sealing ring and O-ring made of FKM on request
*IP69K tested for M12 - M25, M50, M63
