60 Tape Series Datasheet by 3M (TC)

Physical Prop enie: Impe‘zfgmmm) Electrical Properties Impe’m’rzemc) Color - Visual Natural Dielectric Breakdown‘ - Minimum 3000 v Adhesive Thermoeemng Silicone Electrolytic Corrosion Factor-7 1.0 Backing PTFE Film Insulation Resistance’ - Minimum ‘X‘ 012 Q Flame Retardant? Pass Mechanical Properties Impe‘zfgl‘fiwemc) Backing Thickness - Nominal 2 mil (0.051 mm] ”M ”mm“, (0.030: 3 giglmsflsmm) Adhesion to Steel' - Minimum 22 oz/in (2.4 mm) Breaking Strengfh‘ - Minimum 15 \b/in (25 N/cm) www 3M com/regs 3Mtcom/oem
1 of 2
3M™ PTFE Film Electrical Tape 60 with Silicone Adhesive
Data Sheet May 2021
Properties
Notes:
1. ASTM D1000 Test Method - properties measured at room temperature 73°F (23°C) unless otherwise stated
2. UL Recognized Flame Retardant per UL510A Standard
3. 3M Test Method ETM-54001 - 1.0 equates to no corrosion observed
Product Description
3M™ PTFE Film Electrical Tape 60 is a UL recognized flame retardant, natural colored, 3.9-mil
(0.099 mm) thick tape composed of a 2-mil (0.051) thick PTFE film backing coated on one side
with a non-corrosive, thermosetting silicone pressure-sensitive adhesive.
Commonly used for high temperature coils, capacitors and wire harness applications
Adhesive requires no heat, moisture or other manner of preparation to affect application
Designed for continuous operation not exceeding 180°C (356°F)
Physical Properties Value
Imperial (Metric)
Electrical Properties Value
Imperial (Metric)
Color - Visual Natural Dielectric Breakdown1 - Minimum 8000 V
Adhesive Thermosetting Silicone Electrolytic Corrosion Factor3 1.0
Backing
PTFE Film Insulation Resistance1 - Minimum 1x1012 Ω
Flame Retardant2 Pass
Mechanical Properties Value
Imperial (Metric)
Backing Thickness - Nominal 2 mil (0.051 mm)
Total Thickness1 3.9 +/- 0.6 mils
(0.0
+/
-
0
.015
mm)
Adhesion to Steel1 - Minimum
22 oz/in (2.4 N/cm)
Breaking Strength1 - Minimum 15 lb/in (26 N/cm)
Elongation1 - Minimum 110%
Agency Approvals &
Self Certifications
UL Component Recognized: UL510A Standard, Category OARC2, File No. E17385
Self-certified to Commercial Item Description: A-A-59474C (2013), Type I, Class 1
For Regulatory information including RoHS, REACH, please visit www.3M.com/regs
Shelf Life & Storage
This product has a 5-year shelf life (from date of manufacture) when stored in humidity-
controlled storage (50°F/10°C to 80°F/27°C and <75% relative humidity).
Availability
3M™ PTFE Film Electrical Tape 60 available from 3M authorized distributors / converters
Also available from 3M.com/oem or call 1.800.245.3573.
TEC NICAL STATEME www.3M.com/oem
3M™ PTFE Film Electrical Tape 60 with Silicone Adhesive
2 of 2
TECHNICAL STATEMENT
Technical Information: The technical information, guidance, and other statements contained in this document or
otherwise provided by 3M are based upon records, tests, or experience that 3M believes to be reliable, but the
accuracy, completeness, and representative nature of such information is not guaranteed. Such information is
intended for people with knowledge and technical skills sufficient to assess and apply their own informed judgment to
the information. No license under any 3M or third party intellectual property rights is granted or implied with this
information.
Product Selection and Use: Many factors beyond 3M’s control and uniquely within user’s knowledge and control
can affect the use and performance of a 3M product in a particular application. As a result, customer is solely
responsible for evaluating the product and determining whether it is appropriate and suitable for customer’s
application, including conducting a workplace hazard assessment and reviewing all applicable regulations and
standards (e.g., OSHA, ANSI, etc.). Failure to properly evaluate, select, and use a 3M product in accordance with all
applicable instructions and with appropriate safety equipment, or to meet all applicable safety regulations, may result
in injury, sickness, death, and/or harm to property.
Warranty, Limited Remedy, and Disclaimer: Unless a different warranty is specifically stated on the applicable
3M product packaging or product literature (in which case such warranty governs), 3M warrants that each 3M
product meets the applicable 3M product specification at the time 3M ships the product. 3M MAKES NO OTHER
WARRANTIES OR CONDITIONS, EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, ANY
IMPLIED WARRANTY OR CONDITION OF MERCHANTABILITY, FITNESS FOR A PARTICULAR
PURPOSE, OR ARISING OUT OF A COURSE OF DEALING, CUSTOM, OR USAGE OF TRADE. If a 3M
product does not conform to this warranty, then the sole and exclusive remedy is, at 3M’s option, replacement or
repair of the 3M product or refund of the purchase price. Warranty claims must be made within one (1) year from the
date of 3M’s shipment.
Limitation of Liability: Except for the limited remedy stated above, and except to the extent prohibited by
applicable law, 3M will not be liable for any loss or damage arising from or related to the 3M product, whether direct,
indirect, special, incidental, or consequential (including, but not limited to, lost profits or business opportunity),
regardless of the legal or equitable theory asserted, including, but not limited to, warranty, contract, negligence, or
strict liability.
Disclaimer: 3M industrial and occupational products are intended, labeled, and packaged for sale to trained industrial
and occupational customers for workplace use. Unless specifically stated otherwise on the applicable product
packaging or literature, these products are not intended, labeled, or packaged for sale to or use by consumers (e.g., for
home, personal, primary or secondary school, recreational/sporting, or other uses not described in the applicable
product packaging or literature), and must be selected and used in compliance with applicable health and safety
regulations and standards (e.g., U.S. OSHA, ANSI), as well as all product literature, user instructions, warnings, and
limitations, and the user must take any action required under any recall, field action or other product use notice.
Misuse of 3M industrial and occupational products may result in injury, sickness, or death. For help with product
selection and use, consult your on-site safety professional, industrial hygienist, or other subject matter expert. For
additional product information, visit www.3M.com
3M is a trademarks of 3M Company.
Electrical Markets Division
13011 McCallen Pass, Bldg. C Please Recycle. Printed in USA
Austin, TX 78753 © 3M 2021. All Rights Reserved.
Phone: 800.676.8381 78-8124-4714-8 Rev B
www.3M.com/oem
