P512-006 Datasheet by Eaton Tripp Lite

TRIPP°LITE
Specifications
VGA Monitor Cable, 640x480 (HD15 M/M), 6-ft.
MODEL NUMBER: P512-006
Description
Tripp Lite's VGA monitor replacement cable is designed for use with a monitor that has a removable cable
with HD15 connectors. This 6 foot cable has gold plated connectors and gold plated copper contacts to
ensure excellent conductivity. Shielded for maximum EMI/RFI protection. The HD15 male and HD15 male
connectors are molded and have integral strain relief to ensure they last a long time.
For use with monitors with resolutions up to 640x480 ( VGA Std ). For higher resolution monitors, please
use P502-006.
Features
Superior molded cables with foil-shielding for maximum EMI/RFI protection
●
Gold plated connectors and gold plated copper contacts ensure excellent conductivity
●
HD15 male to HD15 male molded connectors
●
Highlights
Superior molded cables with foil-
shielding for maximum EMI/RFI
protection
●
System Requirements
Monitor with removable HD15
cable and resolutions up to
640x480.
●
Package Includes
6-ft. VGA Monitor Cable HD15M
to HD15M Gold Connectors
●
OVERVIEW
UPC Code 037332012364
INPUT
Cable Length (ft.) 6
Cable Length (m) 1.8
PHYSICAL
Color Black
Shipping Dimensions (hwd / cm) 21.59 x 17.53 x 1.27
Shipping Dimensions (hwd / in.) 8.50 x 6.90 x 0.50
1 / 2
TRIPP°LITE
© 2019 Tripp Lite. All rights reserved. All product and company names are trademarks or registered trademarks of their respective holders. Use of them does
not imply any affiliation with or endorsement by them. Tripp Lite has a policy of continuous improvement. Specifications are subject to change without notice.
Tripp Lite uses primary and third-party agencies to test its products for compliance with standards. See a list of Tripp Lite's testing agencies:
https://www.tripplite.com/products/product-certification-agencies
Shipping Weight (kg) 0.14
Shipping Weight (lbs.) 0.30
CONNECTIONS
Side A - Connector 1 HD15 (MALE)
Side B - Connector 1 HD15 (MALE)
FEATURES & SPECIFICATIONS
Technology VGA/SVGA
WARRANTY
Product Warranty Period
(Worldwide) Lifetime limited warranty
2 / 2
