EFM8 Busy Bee Family

EFM8BB1 Data Sheet

The EFM8BB1, part of the Busy Bee family of MCUs, is a multi-

purpose line of 8-bit microcontrollers with a comprehensive feature

set in small packages.

These devices offer high-value by integrating advanced analog and communication pe-

ripherals into small packages, making them ideal for space-constrained applications.

With an efficient 8051 core, enhanced pulse-width modulation, and precision analog, the

EFM8BB1 family is also optimal for embedded applications.

EFM8BB1 applications include the following:

KEY FEATURES

• Pipelined 8-bit C8051 core with 25 MHz

maximum operating frequency

• Up to 18 multifunction, 5 V tolerant I/O

pins

• One 12-bit Analog to Digital converter

(ADC)

• Two low-current analog comparators

• Integrated temperature sensor

• 3-channel enhanced PWM / PCA

• Four 16-bit timers

• UART, SPI and SMBus/I2C

• Priority crossbar for flexible pin mapping

• Motor control

• Consumer electronics

• Sensor controllers

• Medical equipment

• Lighting systems

• I/O port expander

SecurityI/O Ports

Core / Memory Clock Management

Low Frequency

RC Oscillator

Energy Management

Brown-Out Detector

8-bit SFR bus

Serial Interfaces Timers and Triggers Analog Interfaces

UART SPI

I2C / SMBus

External

Interrupts

General Purpose I/O

Pin Reset 16-bit

Timers PCA/PWM

Watchdog Timer

ADC Analog

Comparators

Internal Voltage Reference

16-bit CRC

Flash Program

Memory

(up to 8 KB)

RAM Memory

(up to 512 bytes)

Lowest power mode with peripheral operational:

IdleNormal Shutdown

CIP-51 8051 Core

(25 MHz)

Debug Interface

with C2

External CMOS

Oscillator

High Frequency

RC Oscillator

Internal LDO

Regulator Power-On Reset

silabs.com | Building a more connected world. Rev. 1.6

1. Feature List

The EFM8BB1 highlighted features are listed below.

• Core:

• Pipelined CIP-51 Core

• Fully compatible with standard 8051 instruction set

• 70% of instructions execute in 1-2 clock cycles

• 25 MHz maximum operating frequency

• Memory:

• Up to 8 kB flash memory, in-system re-programmable

from firmware.

• Up to 512 bytes RAM (including 256 bytes standard 8051

RAM and 256 bytes on-chip XRAM)

• Power:

• Internal LDO regulator for CPU core voltage

• Power-on reset circuit and brownout detectors

• I/O: Up to 18 total multifunction I/O pins:

• All pins 5 V tolerant under bias

• Flexible peripheral crossbar for peripheral routing

• 5 mA source, 12.5 mA sink allows direct drive of LEDs

• Clock Sources:

• Internal 24.5 MHz oscillator with ±2% accuracy

• Internal 80 kHz low-frequency oscillator

• External CMOS clock option

• Timers/Counters and PWM:

• 3-channel programmable counter array (PCA) supporting

PWM, capture/compare, and frequency output modes

• 4 x 16-bit general-purpose timers

• Independent watchdog timer, clocked from the low frequen-

cy oscillator

• Communications and Digital Peripherals:

• UART

• SPI™ Master / Slave

• SMBus™/I2C™ Master / Slave

• 16-bit CRC unit, supporting automatic CRC of flash at 256-

byte boundaries

• Analog:

• 12-Bit Analog-to-Digital Converter (ADC)

• 2 x Low-current analog comparators with adjustable refer-

ence

• On-Chip, Non-Intrusive Debugging

• Full memory and register inspection

• Four hardware breakpoints, single-stepping

• Pre-loaded UART bootloader

• Temperature range -40 to 85 ºC or -40 to 125 ºC

• Single power supply 2.2 to 3.6 V

• QSOP24, SOIC16, and QFN20 packages

With on-chip power-on reset, voltage supply monitor, watchdog timer, and clock oscillator, the EFM8BB1 devices are truly standalone

system-on-a-chip solutions. The flash memory is reprogrammable in-circuit, providing non-volatile data storage and allowing field up-

grades of the firmware. The on-chip debugging interface (C2) allows non-intrusive (uses no on-chip resources), full speed, in-circuit

debugging using the production MCU installed in the final application. This debug logic supports inspection and modification of memory

and registers, setting breakpoints, single stepping, and run and halt commands. All analog and digital peripherals are fully functional

while debugging. Each device is specified for 2.2 to 3.6 V operation and is AEC-Q100 qualified. Both the G-grade and I-grade devices

are available in 20-pin QFN, 16-pin SOIC or 24-pin QSOP packages, and A-grade devices are available in the 20-pin QFN package. All

package options are lead-free and RoHS compliant.

EFM8BB1 Data Sheet

Feature List

silabs.com | Building a more connected world. Rev. 1.6 | 2

2. Ordering Information

EFM8 BB1 –0 F 8 G A –QSOP24 R

Tape and Reel (Optional)

Package Type

Revision

Flash Memory Size – 8 KB

Memory Type (Flash)

Family Feature Set

Busy Bee 1 Family

Silicon Labs EFM8 Product Line

Temperature Grade G (-40 to +85), I (-40 to +125), A (-40 to +125, Automotive Grade)

Figure 2.1. EFM8BB1 Part Numbering

All EFM8BB1 family members have the following features:

• CIP-51 Core running up to 25 MHz

• Two Internal Oscillators (24.5 MHz and 80 kHz)

• SMBus / I2C

• SPI

• UART

• 3-Channel Programmable Counter Array (PWM, Clock Generation, Capture/Compare)

• 4 16-bit Timers

• 2 Analog Comparators

• 12-bit Analog-to-Digital Converter with integrated multiplexer, voltage reference, and temperature sensor

• 16-bit CRC Unit

• AEC-Q100 qualified

• Pre-loaded UART bootloader

In addition to these features, each part number in the EFM8BB1 family has a set of features that vary across the product line. The

product selection guide shows the features available on each family member.

Table 2.1. Product Selection Guide

Ordering Part Number

Flash Memory (kB)

RAM (Bytes)

Digital Port I/Os (Total)

ADC0 Channels

Comparator 0 Inputs

Comparator 1 Inputs

Pb-free

(RoHS Compliant)

Temperature Range

Package

EFM8BB10F8G-A-QSOP24 8 512 18 16 8 8 Yes -40 to +85 C QSOP24

EFM8BB10F8G-A-QFN20 8 512 16 15 8 7 Yes -40 to +85 C QFN20

EFM8BB10F8G-A-SOIC16 8 512 13 12 6 6 Yes -40 to +85 C SOIC16

EFM8BB10F4G-A-QFN20 4 512 16 15 8 7 Yes -40 to +85 C QFN20

EFM8BB10F2G-A-QFN20 2 256 16 15 8 7 Yes -40 to +85 C QFN20

EFM8BB1 Data Sheet

Ordering Information

silabs.com | Building a more connected world. Rev. 1.6 | 3

Ordering Part Number

Flash Memory (kB)

RAM (Bytes)

Digital Port I/Os (Total)

ADC0 Channels

Comparator 0 Inputs

Comparator 1 Inputs

Pb-free

(RoHS Compliant)

Temperature Range

Package

EFM8BB10F8I-A-QSOP24 8 512 18 16 8 8 Yes -40 to +125 C QSOP24

EFM8BB10F8I-A-QFN20 8 512 16 15 8 7 Yes -40 to +125 C QFN20

EFM8BB10F8I-A-SOIC16 8 512 13 12 6 6 Yes -40 to +125 C SOIC16

EFM8BB10F4I-A-QFN20 4 512 16 15 8 7 Yes -40 to +125 C QFN20

EFM8BB10F2I-A-QFN20 2 256 16 15 8 7 Yes -40 to +125 C QFN20

EFM8BB10F8A-A-QFN20 8 512 16 15 8 7 Yes -40 to +125 C QFN20

EFM8BB10F4A-A-QFN20 4 512 16 15 8 7 Yes -40 to +125 C QFN20

EFM8BB10F2A-A-QFN20 2 256 16 15 8 7 Yes -40 to +125 C QFN20

The A-grade (i.e. EFM8BB10F8A-A-QFN20) devices receive full automotive quality production status, including AEC-Q100 qualifica-

tion, registration with International Material Data System (IMDS), and Part Production Approval Process (PPAP) documentation. PPAP

documentation is available at www.silabs.com with a registered and NDA approved user account.

EFM8BB1 Data Sheet

Ordering Information

silabs.com | Building a more connected world. Rev. 1.6 | 4

Table of Contents

1. Feature List ................................2

2. Ordering Information ............................3

3. System Overview ..............................7

3.1 Introduction...............................7

3.2 Power ................................8

3.3 I/O..................................8

3.4 Clocking ................................8

3.5 Counters/Timers and PWM .........................9

3.6 Communications and Other Digital Peripherals ...................10

3.7 Analog ................................11

3.8 Reset Sources .............................12

3.9 Debugging ...............................12

3.10 Bootloader ..............................13

4. Electrical Specifications ..........................15

4.1 Electrical Characteristics ..........................15

4.1.1 Recommended Operating Conditions ....................15

4.1.2 Power Consumption..........................16

4.1.3 Reset and Supply Monitor ........................18

4.1.4 Flash Memory ............................19

4.1.5 Internal Oscillators ..........................19

4.1.6 External Clock Input ..........................20

4.1.7 ADC ...............................21

4.1.8 Voltage Reference ..........................22

4.1.9 Temperature Sensor .........................23

4.1.10 1.8 V Internal LDO Voltage Regulator ...................23

4.1.11 Comparators ............................24

4.1.12 Port I/O .............................26

4.1.13 SMBus ..............................27

4.2 Thermal Conditions ............................29

4.3 Absolute Maximum Ratings .........................29

4.4 Typical Performance Curves .........................30

5. Typical Connection Diagrams ........................34

5.1 Power ................................34

5.2 Debug ................................34

5.3 Other Connections ............................35

6. Pin Definitions ..............................36

6.1 EFM8BB1x-QSOP24 Pin Definitions ......................36

6.2 EFM8BB1x-QFN20 Pin Definitions .......................39

silabs.com | Building a more connected world. Rev. 1.6 | 5

6.3 EFM8BB1x-SOIC16 Pin Definitions ......................42

7. QSOP24 Package Specifications .......................44

7.1 QSOP24 Package Dimensions ........................44

7.2 QSOP24 PCB Land Pattern .........................46

7.3 QSOP24 Package Marking .........................47

8. QFN20 Package Specifications........................ 48

8.1 QFN20 Package Dimensions ........................48

8.2 QFN20 PCB Land Pattern .........................50

8.3 QFN20 Package Marking ..........................51

9. SOIC16 Package Specifications .......................52

9.1 SOIC16 Package Dimensions ........................52

9.2 SOIC16 PCB Land Pattern .........................54

9.3 SOIC16 Package Marking ..........................55

10. Revision History............................. 56

10.1 Revision 1.6 ..............................56

10.2 Revision 1.5 ..............................56

10.3 Revision 1.4 ..............................56

10.4 Revision 1.3 ..............................56

10.5 Revision 1.2 ..............................56

10.6 Revision 1.1 ..............................56

silabs.com | Building a more connected world. Rev. 1.6 | 6

3. System Overview

3.1 Introduction

Analog Peripherals

Digital Peripherals

CIP-51 8051 Controller

Core

System Clock

Configuration

AMUX

Priority

Crossbar

Decoder

Crossbar Control

Port I/O Configuration

8/4/2 KB ISP Flash

Program Memory

256 Byte SRAM

SFR

Bus

256 Byte XRAM

CRC

2 Comparators

Power Nets

VDD

GND

SYSCLK

CMOS

Oscillator

Input

24.5 MHz

Oscillator

Debug /

Programming

Hardware

Power On

Reset

C2D

C2CK/RSTb

12/10 bit

ADC Temp

Sensor

VREFVDD

VDD

EXTCLK

Low-Freq.

Oscillator

Independent

Watchdog Timer

Internal

Reference

UART

Timers 0,

1, 2, 3

3-ch PCA

I2C /

SMBus

SPI

Port 0

Drivers

Port 1

Drivers

P0.n

Port 2

Driver P2.n

P1.n

Internal 1.8 V

LDO

Figure 3.1. Detailed EFM8BB1 Block Diagram

This section describes the EFM8BB1 family at a high level. For more information on each module including register definitions, see the

EFM8BB1 Reference Manual.

EFM8BB1 Data Sheet

System Overview

silabs.com | Building a more connected world. Rev. 1.6 | 7

3.2 Power

All internal circuitry draws power from the VDD supply pin. External I/O pins are powered from the VIO supply voltage (or VDD on devi-

ces without a separate VIO connection), while most of the internal circuitry is supplied by an on-chip LDO regulator. Control over the

device power can be achieved by enabling/disabling individual peripherals as needed. Each analog peripheral can be disabled when

not in use and placed in low power mode. Digital peripherals, such as timers and serial buses, have their clocks gated off and draw little

power when they are not in use.

Table 3.1. Power Modes

Power Mode Details Mode Entry Wake-Up Sources

Normal Core and all peripherals clocked and fully operational — —

Idle • Core halted

• All peripherals clocked and fully operational

• Code resumes execution on wake event

Set IDLE bit in PCON0 Any interrupt

Stop • All internal power nets shut down

• Pins retain state

• Exit on any reset source

1. Clear STOPCF bit in

REG0CN

2. Set STOP bit in

PCON0

Any reset source

Shutdown • All internal power nets shut down

• Pins retain state

• Exit on pin or power-on reset

1. Set STOPCF bit in

REG0CN

2. Set STOP bit in

PCON0

• RSTb pin reset

• Power-on reset

3.3 I/O

Digital and analog resources are externally available on the device’s multi-purpose I/O pins. Port pins P0.0-P1.7 can be defined as gen-

eral-purpose I/O (GPIO), assigned to one of the internal digital resources through the crossbar or dedicated channels, or assigned to an

analog function. Port pins P2.0 and P2.1 can be used as GPIO. Additionally, the C2 Interface Data signal (C2D) is shared with P2.0.

• Up to 18 multi-functions I/O pins, supporting digital and analog functions.

• Flexible priority crossbar decoder for digital peripheral assignment.

• Two drive strength settings for each port.

• Two direct-pin interrupt sources with dedicated interrupt vectors (INT0 and INT1).

• Up to 16 direct-pin interrupt sources with shared interrupt vector (Port Match).

3.4 Clocking

The CPU core and peripheral subsystem may be clocked by both internal and external oscillator resources. By default, the system

clock comes up running from the 24.5 MHz oscillator divided by 8.

• Provides clock to core and peripherals.

• 24.5 MHz internal oscillator (HFOSC0), accurate to ±2% over supply and temperature corners.

• 80 kHz low-frequency oscillator (LFOSC0).

• External CMOS clock input (EXTCLK).

• Clock divider with eight settings for flexible clock scaling: Divide the selected clock source by 1, 2, 4, 8, 16, 32, 64, or 128.

EFM8BB1 Data Sheet

System Overview

silabs.com | Building a more connected world. Rev. 1.6 | 8

3.5 Counters/Timers and PWM

Programmable Counter Array (PCA0)

The programmable counter array (PCA) provides multiple channels of enhanced timer and PWM functionality while requiring less CPU

intervention than standard counter/timers. The PCA consists of a dedicated 16-bit counter/timer and one 16-bit capture/compare mod-

ule for each channel. The counter/timer is driven by a programmable timebase that has flexible external and internal clocking options.

Each capture/compare module may be configured to operate independently in one of five modes: Edge-Triggered Capture, Software

Timer, High-Speed Output, Frequency Output, or Pulse-Width Modulated (PWM) Output. Each capture/compare module has its own

associated I/O line (CEXn) which is routed through the crossbar to port I/O when enabled.

• 16-bit time base

• Programmable clock divisor and clock source selection

• Up to three independently-configurable channels

• 8, 9, 10, 11 and 16-bit PWM modes (center or edge-aligned operation)

• Output polarity control

• Frequency output mode

• Capture on rising, falling or any edge

• Compare function for arbitrary waveform generation

• Software timer (internal compare) mode

• Can accept hardware “kill” signal from comparator 0

Timers (Timer 0, Timer 1, Timer 2, and Timer 3)

Several counter/timers are included in the device: two are 16-bit counter/timers compatible with those found in the standard 8051, and

the rest are 16-bit auto-reload timers for timing peripherals or for general purpose use. These timers can be used to measure time inter-

vals, count external events and generate periodic interrupt requests. Timer 0 and Timer 1 are nearly identical and have four primary

modes of operation. The other timers offer both 16-bit and split 8-bit timer functionality with auto-reload and capture capabilities.

Timer 0 and Timer 1 include the following features:

• Standard 8051 timers, supporting backwards-compatibility with firmware and hardware.

• Clock sources include SYSCLK, SYSCLK divided by 12, 4, or 48, the External Clock divided by 8, or an external pin.

• 8-bit auto-reload counter/timer mode

• 13-bit counter/timer mode

• 16-bit counter/timer mode

• Dual 8-bit counter/timer mode (Timer 0)

Timer 2 and Timer 3 are 16-bit timers including the following features:

• Clock sources include SYSCLK, SYSCLK divided by 12, or the External Clock divided by 8.

• 16-bit auto-reload timer mode

• Dual 8-bit auto-reload timer mode

• External pin capture (Timer 2)

• LFOSC0 capture (Timer 3)

Watchdog Timer (WDT0)

The device includes a programmable watchdog timer (WDT) running off the low-frequency oscillator. A WDT overflow forces the MCU

into the reset state. To prevent the reset, the WDT must be restarted by application software before overflow. If the system experiences

a software or hardware malfunction preventing the software from restarting the WDT, the WDT overflows and causes a reset. Following

a reset, the WDT is automatically enabled and running with the default maximum time interval. If needed, the WDT can be disabled by

system software or locked on to prevent accidental disabling. Once locked, the WDT cannot be disabled until the next system reset.

The state of the RST pin is unaffected by this reset.

The Watchdog Timer has the following features:

• Programmable timeout interval

• Runs from the low-frequency oscillator

• Lock-out feature to prevent any modification until a system reset

EFM8BB1 Data Sheet

System Overview

silabs.com | Building a more connected world. Rev. 1.6 | 9

3.6 Communications and Other Digital Peripherals

Universal Asynchronous Receiver/Transmitter (UART0)

UART0 is an asynchronous, full duplex serial port offering modes 1 and 3 of the standard 8051 UART. Enhanced baud rate support

allows a wide range of clock sources to generate standard baud rates. Received data buffering allows UART0 to start reception of a

second incoming data byte before software has finished reading the previous data byte.

The UART module provides the following features:

• Asynchronous transmissions and receptions.

• Baud rates up to SYSCLK/2 (transmit) or SYSCLK/8 (receive).

• 8- or 9-bit data.

• Automatic start and stop generation.

• Single-byte FIFO on transmit and receive.

Serial Peripheral Interface (SPI0)

The serial peripheral interface (SPI) module provides access to a flexible, full-duplex synchronous serial bus. The SPI can operate as a

master or slave device in both 3-wire or 4-wire modes, and supports multiple masters and slaves on a single SPI bus. The slave-select

(NSS) signal can be configured as an input to select the SPI in slave mode, or to disable master mode operation in a multi-master

environment, avoiding contention on the SPI bus when more than one master attempts simultaneous data transfers. NSS can also be

configured as a firmware-controlled chip-select output in master mode, or disabled to reduce the number of pins required. Additional

general purpose port I/O pins can be used to select multiple slave devices in master mode.

The SPI module includes the following features:

• Supports 3- or 4-wire operation in master or slave modes.

• Supports external clock frequencies up to SYSCLK / 2 in master mode and SYSCLK / 10 in slave mode.

• Support for four clock phase and polarity options.

• 8-bit dedicated clock clock rate generator.

• Support for multiple masters on the same data lines.

System Management Bus / I2C (SMB0)

The SMBus I/O interface is a two-wire, bi-directional serial bus. The SMBus is compliant with the System Management Bus Specifica-

tion, version 1.1, and compatible with the I2C serial bus.

The SMBus module includes the following features:

• Standard (up to 100 kbps) and Fast (400 kbps) transfer speeds.

• Support for master, slave, and multi-master modes.

• Hardware synchronization and arbitration for multi-master mode.

• Clock low extending (clock stretching) to interface with faster masters.

• Hardware support for 7-bit slave and general call address recognition.

• Firmware support for 10-bit slave address decoding.

• Ability to inhibit all slave states.

• Programmable data setup/hold times.

16-bit CRC (CRC0)

The cyclic redundancy check (CRC) module performs a CRC using a 16-bit polynomial. CRC0 accepts a stream of 8-bit data and posts

the 16-bit result to an internal register. In addition to using the CRC block for data manipulation, hardware can automatically CRC the

flash contents of the device.

The CRC module is designed to provide hardware calculations for flash memory verification and communications protocols. The CRC

module supports the standard CCITT-16 16-bit polynomial (0x1021), and includes the following features:

• Support for CCITT-16 polynomial

• Byte-level bit reversal

• Automatic CRC of flash contents on one or more 256-byte blocks

• Initial seed selection of 0x0000 or 0xFFFF

EFM8BB1 Data Sheet

System Overview

silabs.com | Building a more connected world. Rev. 1.6 | 10

3.7 Analog

12-Bit Analog-to-Digital Converter (ADC0)

The ADC is a successive-approximation-register (SAR) ADC with 12-, 10-, and 8-bit modes, integrated track-and hold and a program-

mable window detector. The ADC is fully configurable under software control via several registers. The ADC may be configured to

measure different signals using the analog multiplexer. The voltage reference for the ADC is selectable between internal and external

reference sources.

• Up to 16 external inputs.

• Single-ended 12-bit and 10-bit modes.

• Supports an output update rate of 200 ksps samples per second in 12-bit mode or 800 ksps samples per second in 10-bit mode.

• Operation in low power modes at lower conversion speeds.

• Asynchronous hardware conversion trigger, selectable between software, external I/O and internal timer sources.

• Output data window comparator allows automatic range checking.

• Support for burst mode, which produces one set of accumulated data per conversion-start trigger with programmable power-on set-

tling and tracking time.

• Conversion complete and window compare interrupts supported.

• Flexible output data formatting.

• Includes an internal fast-settling reference with two levels (1.65 V and 2.4 V) and support for external reference and signal ground.

• Integrated temperature sensor.

Low Current Comparators (CMP0, CMP1)

Analog comparators are used to compare the voltage of two analog inputs, with a digital output indicating which input voltage is higher.

External input connections to device I/O pins and internal connections are available through separate multiplexers on the positive and

negative inputs. Hysteresis, response time, and current consumption may be programmed to suit the specific needs of the application.

The comparator module includes the following features:

• Up to 8 external positive inputs.

• Up to 8 external negative inputs.

• Additional input options:

• Internal connection to LDO output.

• Direct connection to GND.

• Synchronous and asynchronous outputs can be routed to pins via crossbar.

• Programmable hysteresis between 0 and ±20 mV

• Programmable response time.

• Interrupts generated on rising, falling, or both edges.

EFM8BB1 Data Sheet

System Overview

silabs.com | Building a more connected world. Rev. 1.6 | 11

3.8 Reset Sources

Reset circuitry allows the controller to be easily placed in a predefined default condition. On entry to this reset state, the following occur:

• The core halts program execution.

• Module registers are initialized to their defined reset values unless the bits reset only with a power-on reset.

• External port pins are forced to a known state.

• Interrupts and timers are disabled.

All registers are reset to the predefined values noted in the register descriptions unless the bits only reset with a power-on reset. The

contents of RAM are unaffected during a reset; any previously stored data is preserved as long as power is not lost. The Port I/O latch-

es are reset to 1 in open-drain mode. Weak pullups are enabled during and after the reset. For Supply Monitor and power-on resets,

the RSTb pin is driven low until the device exits the reset state. On exit from the reset state, the program counter (PC) is reset, and the

system clock defaults to an internal oscillator. The Watchdog Timer is enabled, and program execution begins at location 0x0000.

Reset sources on the device include the following:

• Power-on reset

• External reset pin

• Comparator reset

• Software-triggered reset

• Supply monitor reset (monitors VDD supply)

• Watchdog timer reset

• Missing clock detector reset

• Flash error reset

3.9 Debugging

The EFM8BB1 devices include an on-chip Silicon Labs 2-Wire (C2) debug interface to allow flash programming and in-system debug-

ging with the production part installed in the end application. The C2 interface uses a clock signal (C2CK) and a bi-directional C2 data

signal (C2D) to transfer information between the device and a host system. See the C2 Interface Specification for details on the C2

protocol.

EFM8BB1 Data Sheet

System Overview

silabs.com | Building a more connected world. Rev. 1.6 | 12

3.10 Bootloader

All devices come pre-programmed with a UART bootloader. This bootloader resides in the code security page, which is the last last

page of code flash; it can be erased if it is not needed.

The byte before the Lock Byte is the Bootloader Signature Byte. Setting this byte to a value of 0xA5 indicates the presence of the boot-

loader in the system. Any other value in this location indicates that the bootloader is not present in flash.

When a bootloader is present, the device will jump to the bootloader vector after any reset, allowing the bootloader to run. The boot-

loader then determines if the device should stay in bootload mode or jump to the reset vector located at 0x0000. When the bootloader

is not present, the device will jump to the reset vector of 0x0000 after any reset.

More information about the bootloader protocol and usage can be found in AN945: EFM8 Factory Bootloader User Guide. Application

notes can be found on the Silicon Labs website (www.silabs.com/8bit-appnotes) or within Simplicity Studio by using the [Application

Notes] tile.

8 KB Flash

(16 x 512 Byte pages)

Security Page

512 Bytes

0x1E00

0x1FFE

0x1FFF Lock Byte

Reserved

0xFFFF

0x2000

0x0000

0x1FFD

Bootloader Signature Byte

Bootloader

Bootloader Vector

Reset Vector

Figure 3.2. Flash Memory Map with Bootloader—8 KB Devices

Table 3.2. Summary of Pins for Bootloader Communication

Bootloader Pins for Bootload Communication

UART TX – P0.4

RX – P0.5

EFM8BB1 Data Sheet

System Overview

silabs.com | Building a more connected world. Rev. 1.6 | 13

Table 3.3. Summary of Pins for Bootload Mode Entry

Device Package Pin for Bootload Mode Entry

QSOP24 P2.0 / C2D

QFN20 P2.0 / C2D

SOIC16 P2.0 / C2D

EFM8BB1 Data Sheet

System Overview

silabs.com | Building a more connected world. Rev. 1.6 | 14

4. Electrical Specifications

4.1 Electrical Characteristics

All electrical parameters in all tables are specified under the conditions listed in Table 4.1 Recommended Operating Conditions on page

15, unless stated otherwise.

4.1.1 Recommended Operating Conditions

Table 4.1. Recommended Operating Conditions

Parameter Symbol Test Condition Min Typ Max Unit

Operating Supply Voltage on VDD VDD 2.2 — 3.6 V

System Clock Frequency fSYSCLK 0 — 25 MHz

Operating Ambient Temperature TAG-grade devices –40 — 85 °C

I-grade or A-grade devices -40 — 125 °C

Note:

1. All voltages with respect to GND

2. GPIO levels are undefined whenever VDD is less than 1 V.

EFM8BB1 Data Sheet

Electrical Specifications

silabs.com | Building a more connected world. Rev. 1.6 | 15

4.1.2 Power Consumption

Table 4.2. Power Consumption

Parameter Symbol Test Condition Min Typ Max Unit

Digital Core Supply Current (G-grade devices, -40 °C to +85 °C)

Normal Mode—Full speed with

code executing from flash

IDD FSYSCLK = 24.5 MHz2— 4.45 4.85 mA

FSYSCLK = 1.53 MHz2— 915 1150 μA

FSYSCLK = 80 kHz3 , TA = 25 °C — 250 290 μA

FSYSCLK = 80 kHz3— 250 380 μA

Idle Mode—Core halted with pe-

ripherals running

IDD FSYSCLK = 24.5 MHz2— 2.05 2.3 mA

FSYSCLK = 1.53 MHz2— 550 700 μA

FSYSCLK = 80 kHz3 , TA = 25 °C — 125 130 μA

FSYSCLK = 80 kHz3— 125 200 μA

Stop Mode—Core halted and all

clocks stopped,Internal LDO On,

Supply monitor off.

IDD TA = 25 °C — 105 120 μA

TA = -40 to +85 °C — 105 170 μA

Shutdown Mode—Core halted and

all clocks stopped,Internal LDO

Off, Supply monitor off.

IDD — 0.2 — μA

Digital Core Supply Current (I-grade or A-grade devices, -40 °C to +125 °C)

Normal Mode—Full speed with

code executing from flash

IDD FSYSCLK = 24.5 MHz2— 4.45 5.25 mA

FSYSCLK = 1.53 MHz2— 915 1600 μA

FSYSCLK = 80 kHz3 , TA = 25 °C — 250 290 μA

FSYSCLK = 80 kHz3— 250 725 μA

Idle Mode—Core halted with pe-

ripherals running

IDD FSYSCLK = 24.5 MHz2— 2.05 2.6 mA

FSYSCLK = 1.53 MHz2— 550 1000 μA

FSYSCLK = 80 kHz3 , TA = 25 °C — 125 130 μA

FSYSCLK = 80 kHz3— 125 550 μA

Stop Mode—Core halted and all

clocks stopped,Internal LDO On,

Supply monitor off.

IDD TA = 25 °C — 105 120 μA

TA = -40 to +125 °C — 105 270 μA

Shutdown Mode—Core halted and

all clocks stopped,Internal LDO

Off, Supply monitor off.

IDD — 0.2 — μA

Analog Peripheral Supply Currents (-40 °C to +125 °C)

High-Frequency Oscillator IHFOSC Operating at 24.5 MHz,

TA = 25 °C

— 155 — µA

Low-Frequency Oscillator ILFOSC Operating at 80 kHz,

TA = 25 °C

— 3.5 — µA

EFM8BB1 Data Sheet

Electrical Specifications

silabs.com | Building a more connected world. Rev. 1.6 | 16

Parameter Symbol Test Condition Min Typ Max Unit

ADC0 Always-on4IADC 800 ksps, 10-bit conversions or

200 ksps, 12-bit conversions

Normal bias settings

VDD = 3.0 V

— 845 1200 µA

250 ksps, 10-bit conversions or

62.5 ksps 12-bit conversions

Low power bias settings

VDD = 3.0 V

— 425 580 µA

ADC0 Burst Mode, 10-bit single

conversions, external reference

IADC 200 ksps, VDD = 3.0 V — 370 — µA

100 ksps, VDD = 3.0 V — 185 — µA

10 ksps, VDD = 3.0 V — 19 — µA

ADC0 Burst Mode, 10-bit single

conversions, internal reference,

Low power bias settings

IADC 200 ksps, VDD = 3.0 V — 490 — µA

100 ksps, VDD = 3.0 V — 245 — µA

10 ksps, VDD = 3.0 V — 23 — µA

ADC0 Burst Mode, 12-bit single

conversions, external reference

IADC 100 ksps, VDD = 3.0 V — 530 — µA

50 ksps, VDD = 3.0 V — 265 — µA

10 ksps, VDD = 3.0 V — 53 — µA

ADC0 Burst Mode, 12-bit single

conversions, internal reference

IADC 100 ksps, VDD = 3.0 V,

Normal bias

— 950 — µA

50 ksps, VDD = 3.0 V,

Low power bias

— 420 — µA

10 ksps, VDD = 3.0 V,

Low power bias

— 85 — µA

Internal ADC0 Reference, Always-

on5

IVREFFS Normal Power Mode — 680 790 µA

Low Power Mode — 160 210 µA

Temperature Sensor ITSENSE — 75 120 µA

Comparator 0 (CMP0),

Comparator 1 (CMP1)

ICMP CPMD = 11 — 0.5 — µA

CPMD = 10 — 3 — µA

CPMD = 01 — 10 — µA

CPMD = 00 — 25 — µA

Voltage Supply Monitor (VMON0) IVMON — 15 20 µA

EFM8BB1 Data Sheet

Electrical Specifications

silabs.com | Building a more connected world. Rev. 1.6 | 17

Parameter Symbol Test Condition Min Typ Max Unit

Note:

1. Currents are additive. For example, where IDD is specified and the mode is not mutually exclusive, enabling the functions increa-

ses supply current by the specified amount.

2. Includes supply current from internal regulator, supply monitor, and High Frequency Oscillator.

3. Includes supply current from internal regulator, supply monitor, and Low Frequency Oscillator.

4. ADC0 always-on power excludes internal reference supply current.

5. The internal reference is enabled as-needed when operating the ADC in burst mode to save power.

4.1.3 Reset and Supply Monitor

Table 4.3. Reset and Supply Monitor

Parameter Symbol Test Condition Min Typ Max Unit

VDD Supply Monitor Threshold VVDDM 1.8511.95 2.1 V

Power-On Reset (POR) Threshold VPOR Rising Voltage on VDD — 1.4 — V

Falling Voltage on VDD 0.75 — 1.36 V

VDD Ramp Time tRMP Time to VDD ≥ 2.2 V 10 — — µs

Reset Delay from POR tPOR Relative to VDD ≥ VPOR 3 10 31 ms

Reset Delay from non-POR source tRST Time between release of reset

source and code execution

— 39 — µs

RST Low Time to Generate Reset tRSTL 15 — — µs

Missing Clock Detector Response

Time (final rising edge to reset)

tMCD FSYSCLK > 1 MHz — 0.625 1.2 ms

Missing Clock Detector Trigger

Frequency

FMCD — 7.5 13.5 kHz

VDD Supply Monitor Turn-On Time tMON — 2 — µs

Note:

1. MCU core, digital logic, flash memory, and RAM operation is guaranteed down to the minimum VDD Supply Monitor Threshold.

EFM8BB1 Data Sheet

Electrical Specifications

silabs.com | Building a more connected world. Rev. 1.6 | 18

4.1.4 Flash Memory

Table 4.4. Flash Memory

Parameter Symbol Test Condition Min Typ Max Units

Write Time1 ,2 tWRITE One Byte,

FSYSCLK = 24.5 MHz

19 20 21 µs

Erase Time1 ,2 tERASE One Page,

FSYSCLK = 24.5 MHz

5.2 5.35 5.5 ms

VDD Voltage During Programming3VPROG 2.2 — 3.6 V

Endurance (Write/Erase Cycles) NWE 20k 100k — Cycles

CRC Calculation Time tCRC One 256-Byte Block

SYSCLK = 24.5 MHz

— 11 — µs

Note:

1. Does not include sequencing time before and after the write/erase operation, which may be multiple SYSCLK cycles.

2. The internal High-Frequency Oscillator has a programmable output frequency using the HFO0CAL register, which is factory pro-

grammed to 24.5 MHz. If user firmware adjusts the oscillator speed, it must be between 22 and 25 MHz during any flash write or

erase operation. It is recommended to write the HFO0CAL register back to its reset value when writing or erasing flash.

3. Flash can be safely programmed at any voltage above the supply monitor threshold (VVDDM).

4. Data Retention Information is published in the Quarterly Quality and Reliability Report.

4.1.5 Internal Oscillators

Table 4.5. Internal Oscillators

Parameter Symbol Test Condition Min Typ Max Unit

High Frequency Oscillator 0 (24.5 MHz)

Oscillator Frequency fHFOSC0 Full Temperature and Supply

Range

24 24.5 25 MHz

Power Supply Sensitivity PSSHFOS

TA = 25 °C — 0.5 — %/V

Temperature Sensitivity TSHFOSC0 VDD = 3.0 V — 40 — ppm/°C

Low Frequency Oscillator (80 kHz)

Oscillator Frequency fLFOSC Full Temperature and Supply

Range

75 80 85 kHz

Power Supply Sensitivity PSSLFOSC TA = 25 °C — 0.05 — %/V

Temperature Sensitivity TSLFOSC VDD = 3.0 V — 65 — ppm/°C

EFM8BB1 Data Sheet

Electrical Specifications

silabs.com | Building a more connected world. Rev. 1.6 | 19

4.1.6 External Clock Input

Table 4.6. External Clock Input

Parameter Symbol Test Condition Min Typ Max Unit

External Input CMOS Clock

Frequency (at EXTCLK pin)

fCMOS 0 — 25 MHz

External Input CMOS Clock High

Time

tCMOSH 18 — — ns

External Input CMOS Clock Low

Time

tCMOSL 18 — — ns

EFM8BB1 Data Sheet

Electrical Specifications

silabs.com | Building a more connected world. Rev. 1.6 | 20

4.1.7 ADC

Table 4.7. ADC

Parameter Symbol Test Condition Min Typ Max Unit

Resolution Nbits 12 Bit Mode 12 Bits

10 Bit Mode 10 Bits

Throughput Rate

(High Speed Mode)

fS12 Bit Mode — — 200 ksps

10 Bit Mode — — 800 ksps

Throughput Rate

(Low Power Mode)

fS12 Bit Mode — — 62.5 ksps

10 Bit Mode — — 250 ksps

Tracking Time tTRK High Speed Mode 230 — — ns

Low Power Mode 450 — — ns

Power-On Time tPWR 1.2 — — µs

SAR Clock Frequency fSAR High Speed Mode,

Reference is 2.4 V internal

— — 6.25 MHz

High Speed Mode,

Reference is not 2.4 V internal

— — 12.5 MHz

Low Power Mode — — 4 MHz

Conversion Time tCNV 10-Bit Conversion,

SAR Clock = 12.25 MHz,

System Clock = 24.5 MHz.

1.1 µs

Sample/Hold Capacitor CSAR Gain = 1 — 5 — pF

Gain = 0.5 — 2.5 — pF

Input Pin Capacitance CIN — 20 — pF

Input Mux Impedance RMUX — 550 — Ω

Voltage Reference Range VREF 1 — VDD V

Input Voltage Range* VIN Gain = 1 0 — VREF V

Gain = 0.5 0 — 2xVREF V

Power Supply Rejection Ratio PSRRADC — 70 — dB

DC Performance

Integral Nonlinearity INL 12 Bit Mode — ±1 ±2.3 LSB

10 Bit Mode — ±0.2 ±0.6 LSB

Differential Nonlinearity (Guaran-

teed Monotonic)

DNL 12 Bit Mode –1 ±0.7 1.9 LSB

10 Bit Mode — ±0.2 ±0.6 LSB

Offset Error EOFF 12 Bit Mode, VREF = 1.65 V –3 0 3 LSB

10 Bit Mode, VREF = 1.65 V –2 0 2 LSB

Offset Temperature Coefficient TCOFF — 0.004 — LSB/°C

EFM8BB1 Data Sheet

Electrical Specifications

silabs.com | Building a more connected world. Rev. 1.6 | 21

Parameter Symbol Test Condition Min Typ Max Unit

Slope Error EM12 Bit Mode — ±0.02 ±0.1 %

10 Bit Mode — ±0.06 ±0.24 %

Dynamic Performance 10 kHz Sine Wave Input 1dB below full scale, Max throughput, using AGND pin

Signal-to-Noise SNR 12 Bit Mode 61 66 — dB

10 Bit Mode 53 60 — dB

Signal-to-Noise Plus Distortion SNDR 12 Bit Mode 61 66 — dB

10 Bit Mode 53 60 — dB

Total Harmonic Distortion (Up to

5th Harmonic)

THD 12 Bit Mode — 71 — dB

10 Bit Mode — 70 — dB

Spurious-Free Dynamic Range SFDR 12 Bit Mode — –79 — dB

10 Bit Mode — –74 — dB

Note:

1. Absolute input pin voltage is limited by the VDD supply.

4.1.8 Voltage Reference

Table 4.8. Voltage Reference

Parameter Symbol Test Condition Min Typ Max Unit

Internal Fast Settling Reference

Output Voltage

(Full Temperature and Supply

Range)

VREFFS 1.65 V Setting 1.62 1.65 1.68 V

2.4 V Setting, VDD ≥ 2.6 V 2.35 2.4 2.45 V

Temperature Coefficient TCREFFS — 50 — ppm/°C

Turn-on Time tREFFS — — 1.5 µs

Power Supply Rejection PSRRREF

— 400 — ppm/V

External Reference

Input Current IEXTREF Sample Rate = 800 ksps; VREF =

3.0 V

— 5 — µA

EFM8BB1 Data Sheet

Electrical Specifications

silabs.com | Building a more connected world. Rev. 1.6 | 22

4.1.9 Temperature Sensor

Table 4.9. Temperature Sensor

Parameter Symbol Test Condition Min Typ Max Unit

Offset VOFF TA = 0 °C — 757 — mV

Offset Error1EOFF TA = 0 °C — 17 — mV

Slope M — 2.85 — mV/°C

Slope Error1EM— 70 — µV/°C

Linearity — 0.5 — °C

Turn-on Time — 1.8 — µs

Note:

1. Represents one standard deviation from the mean.

4.1.10 1.8 V Internal LDO Voltage Regulator

Table 4.10. 1.8V Internal LDO Voltage Regulator

Parameter Symbol Test Condition Min Typ Max Unit

Output Voltage VOUT_1.8V 1.74 1.8 1.85 V

EFM8BB1 Data Sheet

Electrical Specifications

silabs.com | Building a more connected world. Rev. 1.6 | 23

4.1.11 Comparators

Table 4.11. Comparators

Parameter Symbol Test Condition Min Typ Max Unit

Response Time, CPMD = 00

(Highest Speed)

tRESP0 +100 mV Differential — 100 — ns

–100 mV Differential — 150 — ns

Response Time, CPMD = 11 (Low-

est Power)

tRESP3 +100 mV Differential — 1.5 — µs

–100 mV Differential — 3.5 — µs

Positive Hysterisis

Mode 0 (CPMD = 00)

HYSCP+ CPHYP = 00 — 0.4 — mV

CPHYP = 01 — 8 — mV

CPHYP = 10 — 16 — mV

CPHYP = 11 — 32 — mV

Negative Hysterisis

Mode 0 (CPMD = 00)

HYSCP- CPHYN = 00 — -0.4 — mV

CPHYN = 01 — –8 — mV

CPHYN = 10 — –16 — mV

CPHYN = 11 — –32 — mV

Positive Hysterisis

Mode 1 (CPMD = 01)

HYSCP+ CPHYP = 00 — 0.5 — mV

CPHYP = 01 — 6 — mV

CPHYP = 10 — 12 — mV

CPHYP = 11 — 24 — mV

Negative Hysterisis

Mode 1 (CPMD = 01)

HYSCP- CPHYN = 00 — -0.5 — mV

CPHYN = 01 — –6 — mV

CPHYN = 10 — –12 — mV

CPHYN = 11 — –24 — mV

Positive Hysterisis

Mode 2 (CPMD = 10)

HYSCP+ CPHYP = 00 — 0.7 — mV

CPHYP = 01 — 4.5 — mV

CPHYP = 10 — 9 — mV

CPHYP = 11 — 18 — mV

Negative Hysterisis

Mode 2 (CPMD = 10)

HYSCP- CPHYN = 00 — -0.6 — mV

CPHYN = 01 — –4.5 — mV

CPHYN = 10 — –9 — mV

CPHYN = 11 — –18 — mV

Positive Hysteresis

Mode 3 (CPMD = 11)

HYSCP+ CPHYP = 00 — 1.5 — mV

CPHYP = 01 — 4 — mV

CPHYP = 10 — 8 — mV

CPHYP = 11 — 16 — mV

EFM8BB1 Data Sheet

Electrical Specifications

silabs.com | Building a more connected world. Rev. 1.6 | 24

Parameter Symbol Test Condition Min Typ Max Unit

Negative Hysteresis

Mode 3 (CPMD = 11)

HYSCP- CPHYN = 00 — -1.5 — mV

CPHYN = 01 — –4 — mV

CPHYN = 10 — –8 — mV

CPHYN = 11 — –16 — mV

Input Range (CP+ or CP–) VIN -0.25 — VDD+0.25 V

Input Pin Capacitance CCP — 7.5 — pF

Common-Mode Rejection Ratio CMRRCP — 70 — dB

Power Supply Rejection Ratio PSRRCP — 72 — dB

Input Offset Voltage VOFF TA = 25 °C -10 0 10 mV

Input Offset Tempco TCOFF — 3.5 — µV/°C

EFM8BB1 Data Sheet

Electrical Specifications

silabs.com | Building a more connected world. Rev. 1.6 | 25

4.1.12 Port I/O

Table 4.12. Port I/O

Parameter Symbol Test Condition Min Typ Max Unit

Output High Voltage (Low Drive)1VOH IOH = –1 mA VDD – 0.7 — — V

Output High Voltage (High Drive)1VOH IOH = –3 mA VDD – 0.7 — — V

Output Low Voltage (Low Drive)1VOL IOL = 1.4 mA — — 0.6 V

Output Low Voltage (High Drive)1VOL IOL = 8.5 mA — — 0.6 V

Output Low Voltage (High Drive)1VOL IOL = 10 mA

-10 °C ≤ TA ≤ 60 °C

VDD = 3.0 V

Guaranteed by characterization

— 0.25 0.33 V

Output Low Voltage (High Drive)1VOL IOL = 10 mA

-10 °C ≤ TA ≤ 60 °C

VDD = 3.6 V

Guaranteed by characterization

— 0.23 0.31 V

Input High Voltage VIH VDD – 0.6 — — V

Input Low Voltage VIL — — 0.6 V

Pin Capacitance CIO — 7 — pF

Weak Pull-Up Current

(VIN = 0 V)

IPU VDD = 3.6 –30 –20 –10 µA

Input Leakage (Pullups off or Ana-

log)

ILK GND < VIN < VDD –1.1 — 1.1 µA

Input Leakage Current with VIN

above VDD

ILK VDD < VIN < VDD+2.0 V 0 5 150 µA

Note:

1. See Figure 4.6 Typical VOH Curves on page 33 and Figure 4.7 Typical VOL Curves on page 33 for more information.

EFM8BB1 Data Sheet

Electrical Specifications

silabs.com | Building a more connected world. Rev. 1.6 | 26

4.1.13 SMBus

Table 4.13. SMBus Peripheral Timing Performance (Master Mode)

Parameter Symbol Test Condition Min Typ Max Unit

Standard Mode (100 kHz Class)

I2C Operating Frequency fI2C 0 — 702kHz

SMBus Operating Frequency fSMB 401—702kHz

Bus Free Time Between STOP and

START Conditions

tBUF 9.4 — — µs

Hold Time After (Repeated)

START Condition

tHD:STA 4.7 — — µs

Repeated START Condition Setup

Time

tSU:STA 9.4 — — µs

STOP Condition Setup Time tSU:STO 9.4 — — µs

Data Hold Time tHD:DAT 4893— — ns

Data Setup Time tSU:DAT 4483— — ns

Detect Clock Low Timeout tTIMEOUT 25 — — ms

Clock Low Period tLOW 4.7 — — µs

Clock High Period tHIGH 9.4 — 504µs

Fast Mode (400 kHz Class)

I2C Operating Frequency fI2C 0 — 2552kHz

SMBus Operating Frequency fSMB 401—2552kHz

Bus Free Time Between STOP and

START Conditions

tBUF 2.6 — — µs

Hold Time After (Repeated)

START Condition

tHD:STA 1.3 — — µs

Repeated START Condition Setup

Time

tSU:STA 2.6 — — µs

STOP Condition Setup Time tSU:STO 2.6 — — µs

Data Hold Time tHD:DAT 4893— — ns

Data Setup Time tSU:DAT 4483— — ns

Detect Clock Low Timeout tTIMEOUT 25 — — ms

Clock Low Period tLOW 1.3 — — µs

Clock High Period tHIGH 2.6 — 504µs

EFM8BB1 Data Sheet

Electrical Specifications

silabs.com | Building a more connected world. Rev. 1.6 | 27

Parameter Symbol Test Condition Min Typ Max Unit

Note:

1. The minimum SMBus frequency is limited by the maximum Clock High Period requirement of the SMBus specification.

2. The maximum I2C and SMBus frequencies are limited by the minimum Clock Low Period requirements of their respective specifi-

cations. The maximum frequency cannot be achieved with all combinations of oscillators and dividers available, but the effective

frequency must not exceed 256 kHz.

3. Data setup and hold timing at 25 MHz or lower with EXTHOLD set to 1.

4. SMBus has a maximum requirement of 50 µs for Clock High Period. Operating frequencies lower than 40 kHz will be longer than

50 µs. I2C can support periods longer than 50 µs.

Table 4.14. SMBus Peripheral Timing Formulas (Master Mode)

Parameter Symbol Clocks

SMBus Operating Frequency fSMB fCSO / 3

Bus Free Time Between STOP and START Conditions tBUF 2 / fCSO

Hold Time After (Repeated) START Condition tHD:STA 1 / fCSO

Repeated START Condition Setup Time tSU:STA 2 / fCSO

STOP Condition Setup Time tSU:STO 2 / fCSO

Clock Low Period tLOW 1 / fCSO

Clock High Period tHIGH 2 / fCSO

Note:

1. fCSO is the SMBus peripheral clock source overflow frequency.

tLOW

S PSP

VIH

VIL

VIH

VIL

SCL

SDA

tBUF

tHD:STA tHD:DAT

tHIGH

tSU:DAT

tSU:STA tSU:STO

Figure 4.1. SMBus Peripheral Timing Diagram (Master Mode)

EFM8BB1 Data Sheet

Electrical Specifications

silabs.com | Building a more connected world. Rev. 1.6 | 28

4.2 Thermal Conditions

Table 4.15. Thermal Conditions

Parameter Symbol Test Condition Min Typ Max Unit

Thermal Resistance (Junction to

Ambient)

θJA SOIC-16 Packages — 70 — °C/W

QFN-20 Packages — 60 — °C/W

QSOP-24 Packages — 65 — °C/W

Thermal Resistance (Junction to

Case)

θJC QFN-20 Packages ─ 28.86 ─ °C/W

Note:

1. Thermal resistance assumes a multi-layer PCB with any exposed pad soldered to a PCB pad.

4.3 Absolute Maximum Ratings

Stresses above those listed in Table 4.16 Absolute Maximum Ratings on page 29 may cause permanent damage to the device. This

is a stress rating only and functional operation of the devices at those or any other conditions above those indicated in the operation

listings of this specification is not implied. Exposure to maximum rating conditions for extended periods may affect device reliability. For

more information on the available quality and reliability data, see the Quality and Reliability Monitor Report at http://www.silabs.com/

support/quality/pages/default.aspx.

Table 4.16. Absolute Maximum Ratings

Parameter Symbol Test Condition Min Max Unit

Ambient Temperature Under Bias TBIAS –55 125 °C

Storage Temperature TSTG –65 150 °C

Voltage on VDD VDD GND–0.3 4.2 V

Voltage on I/O pins or RST VIN VDD ≥ 3.3 V GND–0.3 5.8 V

V < 3.3 V GND–0.3 VDD+2.5 V

Total Current Sunk into Supply Pin IVDD — 200 mA

Total Current Sourced out of Ground

IGND 200 — mA

Current Sourced or Sunk by Any I/O

Pin or RSTb

IIO -100 100 mA

Operating Junction Temperature TJTA = -40 °C to 85 °C –40 105 °C

TA = -40 °C to 125 °C (I-grade or A-

grade parts only)

-40 130 °C

Exposure to maximum rating conditions for extended periods may affect device reliability.

EFM8BB1 Data Sheet

Electrical Specifications

silabs.com | Building a more connected world. Rev. 1.6 | 29

Supply Current (mA) Supp‘y Current (mA) — Nema‘ Mode — menace 0.30 5 10 15 20 25 Operating Frequency (MHZ) 025 0.20 015 — Nerrnamode — Id‘eMade 0.10 , 005* 0.00 10 r r r 20 3o 40 so so 70 so Operating Frequency (kHz)

4.4 Typical Performance Curves

Figure 4.2. Typical Operating Supply Current using HFOSC0

Figure 4.3. Typical Operating Supply Current using LFOSC

EFM8BB1 Data Sheet

Electrical Specifications

silabs.com | Building a more connected world. Rev. 1.6 | 30

Supply Current (uA) lorbit Burst Mode, Single Conversions erbit Burst Mode, Single Conversions 1200 ‘ ‘ 1200 ‘ ‘ ‘ — Nurmai Bias, imamal Refevence — Mormai Blas. intemai Referenm — u: Bias, inlemai Meme: — LP Bias, imemai Refaranze 1000 — Extemai orVDD Reierence _ _ 7 1000 — Exiemai 9mm Refevence _ _ _ 7 800 , . . . . . . , g 300 , . . . . . . , ‘E Q 500 , . . . . . 7 ‘5 600 7 . . . . . . , U > E. 409 7 . . . . . 7 § 400 7 . . . . . . 7 m 200 7 . . . . . 7 200 7 . . . . . 7 0 i i i i i i 0 i i i i i i 0 50 100 150 200 250 300 0 20 40 60 80 100 120 Sample Rate (ksps) Sampie Rate (ksps)

Figure 4.4. Typical ADC0 and Internal Reference Supply Current in Burst Mode

EFM8BB1 Data Sheet

Electrical Specifications

silabs.com | Building a more connected world. Rev. 1.6 | 31

Supp‘y Current (uA) Supp‘y Current (MA) 107bit Conversions, Norma‘ Bias lorbit Conversions, Low Power Bias 900 ‘ ‘ ‘ ‘ ‘ ‘ — qu:35v — VDD=3V 430 350 — vDD=22v 3 420 3 300 E 410 E 400 U 75° E 390 a 3 m 380 700 370 550 ‘ ‘ ‘ ‘ ‘ ‘ 360 ‘ ‘ ‘ 100 200 300 400 500 600 700 900 so 100 150 200 250 Sample Rate (ksps) Samp‘e Rate (ksps) 900 12-bit Conversions, Norma‘ Bias 450 12-bit Conversions, Low Power Bias — VDD=36V ‘ ‘ ‘ ‘ ‘ — VDD=36V ‘ ‘ ‘ ‘ — van: 3v 44o — VDD=2 2V 35“ A 430 <( a="" 420="" 300="" ‘5="" 2="" 410="" 3="" u="" 400="" 750="" 3="" 2="" 390="" s="" 700="" 380="" 370="" 650="" ‘="" ‘="" ‘="" ‘="" ‘="" ‘="" ‘="" ‘="" 360="" ‘="" ‘="" ‘="" ‘="" 40="" 60="" so="" 100="" 120="" 140="" 160="" 180="" 200="" sample="" rate="" (ksps)="" 10="" 20="" ‘="" 30="" 40="" samp‘e="" rate="" (ksps)="">

Figure 4.5. Typical ADC0 Supply Current in Normal (always-on) Mode

EFM8BB1 Data Sheet

Electrical Specifications

silabs.com | Building a more connected world. Rev. 1.6 | 32

Vokage Voltage Typical VOH (Low Drive Mode) Typical VOH (High Drive Mode) l l l 3-5’ —vDD=36v 357 -‘ _ — VDD=33V — — vDD=27v _ — VDD=22V — VDD=22V 3 o 7 3.0 7 2.5 7 7 m 2 5 7 7 m E T: 207 7 > 107 7 1 5 7 7 1.5 7 7 1.0 , . . . . , 1.0 , . . . . . . . , l l l l l l l l l l l 0 5 10 15 20 25 o 2 A 6 s 10 12 14 16 Load Current (mA) Load Current(mA) 1 3 Typical VOL (High Drive Mode) 1 8 Typical VOL (Low Drive Mode) - l l l l l l _ “ma-6V - l l l 15, —vuu=33v 167 I — VDD=2.7V — VDD=2.2V — VDD=22V 1.4 7 1 4 7 1 2 7 7 1.2 7 7 1.0 7 7 g 1.0 7 7 E 087 7 g 037 7 o a 7 7 0.6 7 7 0.4 7 7 0.4 7 7 0.2 7 7 0 2 7 7 0 l l l l l l l l 0.0 l l l l —45 —40 —35 —30 —25 -20 -15 -10 -5 0 -25 -20 -15 -10 -5 0 Load Current (mA) Load Current (mA)

Figure 4.6. Typical VOH Curves

Figure 4.7. Typical VOL Curves

EFM8BB1 Data Sheet

Electrical Specifications

silabs.com | Building a more connected world. Rev. 1.6 | 33

5. Typical Connection Diagrams

5.1 Power

Figure 5.1 Power Connection Diagram on page 34 shows a typical connection diagram for the power pins of the EFM8BB1 devices.

EFM8BB1

Device

GND

1 µF and 0.1 µF bypass

capacitors required for

the power pins placed

as close to the pins as

possible.

2.2-3.6 V (in)

VDD

Figure 5.1. Power Connection Diagram

5.2 Debug

The diagram below shows a typical connection diagram for the debug connections pins. The pin sharing resistors are only required if

the functionality on the C2D (a GPIO pin) and the C2CK (RSTb) is routed to external circuitry. For example, if the RSTb pin is connec-

ted to an external switch with debouncing filter or if the GPIO sharing with the C2D pin is connected to an external circuit, the pin shar-

ing resistors and connections to the debug adapter must be placed on the hardware. Otherwise, these components and connections

can be omitted.

For more information on debug connections, see the example schematics and information available in application note, AN124: Pin

Sharing Techniques for the C2 Interface. Application notes can be found on the Silicon Labs website (http://www.silabs.com/8bit-app-

notes) or in Simplicity Studio.

EFM8BB1 Device External

System

(if pin sharing)

1 k 1 k

(if pin sharing)

C2CK

1 k 1 k

Debug Adapter

1 k

VDD

C2D

GND

Figure 5.2. Debug Connection Diagram

EFM8BB1 Data Sheet

Typical Connection Diagrams

silabs.com | Building a more connected world. Rev. 1.6 | 34

5.3 Other Connections

Other components or connections may be required to meet the system-level requirements. Application note, "AN203: 8-bit MCU Printed

Circuit Board Design Notes", contains detailed information on these connections. Application Notes can be accessed on the Silicon

Labs website (www.silabs.com/8bit-appnotes).

EFM8BB1 Data Sheet

Typical Connection Diagrams

silabs.com | Building a more connected world. Rev. 1.6 | 35

6. Pin Definitions

6.1 EFM8BB1x-QSOP24 Pin Definitions

P0.2

P0.1

P0.0

GND

VDD

RSTb / C2CK

C2D / P2.0

N/C

P0.4

P0.5

P0.6

P0.7

P1.0

P1.1

P1.2

P1.3

P1.4

24 pin QSOP

(Top View)

N/C

P2.1

P1.5

P1.6

P1.7

N/C

P0.3

Figure 6.1. EFM8BB1x-QSOP24 Pinout

Table 6.1. Pin Definitions for EFM8BB1x-QSOP24

Number

Pin Name Description Crossbar Capability Additional Digital

Functions

Analog Functions

1 N/C No Connection

2 P0.2 Multifunction I/O Yes P0MAT.2

INT0.2

INT1.2

ADC0.2

CMP0P.2

CMP0N.2

EFM8BB1 Data Sheet

Pin Definitions

silabs.com | Building a more connected world. Rev. 1.6 | 36

Number

Pin Name Description Crossbar Capability Additional Digital

Functions

Analog Functions

3 P0.1 Multifunction I/O Yes P0MAT.1

INT0.1

INT1.1

ADC0.1

CMP0P.1

CMP0N.1

AGND

4 P0.0 Multifunction I/O Yes P0MAT.0

INT0.0

INT1.0

ADC0.0

CMP0P.0

CMP0N.0

VREF

5 GND Ground

6 VDD Supply Power Input

7 RSTb /

C2CK

Active-low Reset /

C2 Debug Clock

8 P2.0 /

C2D

Multifunction I/O /

C2 Debug Data

9 P1.7 Multifunction I/O Yes P1MAT.7 ADC0.15

CMP1P.7

CMP1N.7

10 P1.6 Multifunction I/O Yes P1MAT.6 ADC0.14

CMP1P.6

CMP1N.6

11 P1.5 Multifunction I/O Yes P1MAT.5 ADC0.13

CMP1P.5

CMP1N.5

12 P2.1 Multifunction I/O

13 N/C No Connection

14 P1.4 Multifunction I/O Yes P1MAT.4 ADC0.12

CMP1P.4

CMP1N.4

15 P1.3 Multifunction I/O Yes P1MAT.3 ADC0.11

CMP1P.3

CMP1N.3

16 P1.2 Multifunction I/O Yes P1MAT.2 ADC0.10

CMP1P.2

CMP1N.2

EFM8BB1 Data Sheet

Pin Definitions

silabs.com | Building a more connected world. Rev. 1.6 | 37

Number

Pin Name Description Crossbar Capability Additional Digital

Functions

Analog Functions

17 P1.1 Multifunction I/O Yes P1MAT.1 ADC0.9

CMP1P.1

CMP1N.1

18 P1.0 Multifunction I/O Yes P1MAT.0 ADC0.8

CMP1P.0

CMP1N.0

19 P0.7 Multifunction I/O Yes P0MAT.7

INT0.7

INT1.7

ADC0.7

CMP0P.7

CMP0N.7

20 P0.6 Multifunction I/O Yes P0MAT.6

CNVSTR

INT0.6

INT1.6

ADC0.6

CMP0P.6

CMP0N.6

21 P0.5 Multifunction I/O Yes P0MAT.5

INT0.5

INT1.5

ADC0.5

CMP0P.5

CMP0N.5

22 P0.4 Multifunction I/O Yes P0MAT.4

INT0.4

INT1.4

ADC0.4

CMP0P.4

CMP0N.4

23 P0.3 Multifunction I/O Yes P0MAT.3

EXTCLK

INT0.3

INT1.3

ADC0.3

CMP0P.3

CMP0N.3

24 N/C No Connection

EFM8BB1 Data Sheet

Pin Definitions

silabs.com | Building a more connected world. Rev. 1.6 | 38

gccr JUUL Wﬂﬂf 4::j

6.2 EFM8BB1x-QFN20 Pin Definitions

20 pin QFN

(Top View)

P0.1

P0.0

GND

VDD

RSTb / C2CK

P2.0 / C2D

P0.6

P0.7

P1.0

P1.1

GND

P1.2

P0.2

P0.3

P0.4

P0.5

GND

6 11

P1.6

P1.5

P1.4

P1.3

Figure 6.2. EFM8BB1x-QFN20 Pinout

Table 6.2. Pin Definitions for EFM8BB1x-QFN20

Number

Pin Name Description Crossbar Capability Additional Digital

Functions

Analog Functions

1 P0.1 Multifunction I/O Yes P0MAT.1

INT0.1

INT1.1

ADC0.1

CMP0P.1

CMP0N.1

AGND

2 P0.0 Multifunction I/O Yes P0MAT.0

INT0.0

INT1.0

ADC0.0

CMP0P.0

CMP0N.0

VREF

EFM8BB1 Data Sheet

Pin Definitions

silabs.com | Building a more connected world. Rev. 1.6 | 39

Number

Pin Name Description Crossbar Capability Additional Digital

Functions

Analog Functions

3 GND Ground

4 VDD Supply Power Input

5 RSTb /

C2CK

Active-low Reset /

C2 Debug Clock

6 P2.0 /

C2D

Multifunction I/O /

C2 Debug Data

7 P1.6 Multifunction I/O Yes P1MAT.6 ADC0.14

CMP1P.6

CMP1N.6

8 P1.5 Multifunction I/O Yes P1MAT.5 ADC0.13

CMP1P.5

CMP1N.5

9 P1.4 Multifunction I/O Yes P1MAT.4 ADC0.12

CMP1P.4

CMP1N.4

10 P1.3 Multifunction I/O Yes P1MAT.3 ADC0.11

CMP1P.3

CMP1N.3

11 P1.2 Multifunction I/O Yes P1MAT.2 ADC0.10

CMP1P.2

CMP1N.2

12 GND Ground

13 P1.1 Multifunction I/O Yes P1MAT.1 ADC0.9

CMP1P.1

CMP1N.1

14 P1.0 Multifunction I/O Yes P1MAT.0 ADC0.8

CMP1P.0

CMP1N.0

15 P0.7 Multifunction I/O Yes P0MAT.7

INT0.7

INT1.7

ADC0.7

CMP0P.7

CMP0N.7

16 P0.6 Multifunction I/O Yes P0MAT.6

CNVSTR

INT0.6

INT1.6

ADC0.6

CMP0P.6

CMP0N.6

EFM8BB1 Data Sheet

Pin Definitions

silabs.com | Building a more connected world. Rev. 1.6 | 40

Number

Pin Name Description Crossbar Capability Additional Digital

Functions

Analog Functions

17 P0.5 Multifunction I/O Yes P0MAT.5

INT0.5

INT1.5

ADC0.5

CMP0P.5

CMP0N.5

18 P0.4 Multifunction I/O Yes P0MAT.4

INT0.4

INT1.4

ADC0.4

CMP0P.4

CMP0N.4

19 P0.3 Multifunction I/O Yes P0MAT.3

EXTCLK

INT0.3

INT1.3

ADC0.3

CMP0P.3

CMP0N.3

20 P0.2 Multifunction I/O Yes P0MAT.2

INT0.2

INT1.2

ADC0.2

CMP0P.2

CMP0N.2

Center GND Ground

EFM8BB1 Data Sheet

Pin Definitions

silabs.com | Building a more connected world. Rev. 1.6 | 41

:::::::: O ::::::::

6.3 EFM8BB1x-SOIC16 Pin Definitions

P0.2

P0.1

P0.0

GND

VDD

RSTb / C2CK

P2.0 / C2D

P1.3

P0.3

P0.4

P0.5

P0.6

P0.7

P1.0

P1.1

P1.2

16 pin SOIC

(Top View)

8 9

Figure 6.3. EFM8BB1x-SOIC16 Pinout

Table 6.3. Pin Definitions for EFM8BB1x-SOIC16

Number

Pin Name Description Crossbar Capability Additional Digital

Functions

Analog Functions

1 P0.2 Multifunction I/O Yes P0MAT.2

INT0.2

INT1.2

ADC0.2

CMP0P.2

CMP0N.2

2 P0.1 Multifunction I/O Yes P0MAT.1

INT0.1

INT1.1

ADC0.1

CMP0P.1

CMP0N.1

3 P0.0 Multifunction I/O Yes P0MAT.0

INT0.0

INT1.0

ADC0.0

CMP0P.0

CMP0N.0

EFM8BB1 Data Sheet

Pin Definitions

silabs.com | Building a more connected world. Rev. 1.6 | 42

Number

Pin Name Description Crossbar Capability Additional Digital

Functions

Analog Functions

4 GND Ground

5 VDD Supply Power Input

6 RSTb /

C2CK

Active-low Reset /

C2 Debug Clock

7 P2.0 /

C2D

Multifunction I/O /

C2 Debug Data

8 P1.3 Multifunction I/O Yes P1MAT.3 ADC0.11

CMP1P.5

CMP1N.5

9 P1.2 Multifunction I/O Yes P1MAT.2 ADC0.10

CMP1P.4

CMP1N.4

10 P1.1 Multifunction I/O Yes P1MAT.1 ADC0.9

CMP1P.3

CMP1N.3

11 P1.0 Multifunction I/O Yes P1MAT.0 ADC0.8

CMP1P.2

CMP1N.2

12 P0.7 Multifunction I/O Yes P0MAT.7

INT0.7

INT1.7

ADC0.7

CMP1P.1

CMP1N.1

13 P0.6 Multifunction I/O Yes P0MAT.6

CNVSTR

INT0.6

INT1.6

ADC0.6

CMP1P.0

CMP1N.0

14 P0.5 Multifunction I/O Yes P0MAT.5

INT0.5

INT1.5

ADC0.5

CMP0P.5

CMP0N.5

15 P0.4 Multifunction I/O Yes P0MAT.4

INT0.4

INT1.4

ADC0.4

CMP0P.4

CMP0N.4

16 P0.3 Multifunction I/O Yes P0MAT.3

EXTCLK

INT0.3

INT1.3

ADC0.3

CMP0P.3

CMP0N.3

EFM8BB1 Data Sheet

Pin Definitions

silabs.com | Building a more connected world. Rev. 1.6 | 43

(2x) E1 (ex 12 Ups) I 0- a 7 7 ‘ 7 7 [E] O ‘ ‘ w wwmm H L “mama T E gmaﬁw Seuﬂn Plane 6 Dem“ 1 _F \ f—i'L ‘ \ ﬁ Deta‘l l

7. QSOP24 Package Specifications

7.1 QSOP24 Package Dimensions

Figure 7.1. QSOP24 Package Drawing

Table 7.1. QSOP24 Package Dimensions

Dimension Min Typ Max

A — — 1.75

A1 0.10 — 0.25

b 0.20 — 0.30

c 0.10 — 0.25

D 8.65 BSC

E 6.00 BSC

E1 3.90 BSC

e 0.635 BSC

L 0.40 — 1.27

EFM8BB1 Data Sheet

QSOP24 Package Specifications

silabs.com | Building a more connected world. Rev. 1.6 | 44

Dimension Min Typ Max

theta 0º — 8º

aaa 0.20

bbb 0.18

ccc 0.10

ddd 0.10

Note:

1. All dimensions shown are in millimeters (mm) unless otherwise noted.

2. Dimensioning and Tolerancing per ANSI Y14.5M-1994.

3. This drawing conforms to JEDEC outline MO-137, variation AE.

4. Recommended card reflow profile is per the JEDEC/IPC J-STD-020 specification for Small Body Components.

EFM8BB1 Data Sheet

QSOP24 Package Specifications

silabs.com | Building a more connected world. Rev. 1.6 | 45

4% Egg E EEEEEEEE

7.2 QSOP24 PCB Land Pattern

Figure 7.2. QSOP24 PCB Land Pattern Drawing

Table 7.2. QSOP24 PCB Land Pattern Dimensions

Dimension Min Max

C 5.20 5.30

E 0.635 BSC

X 0.30 0.40

Y 1.50 1.60

Note:

1. All dimensions shown are in millimeters (mm) unless otherwise noted.

2. This land pattern design is based on the IPC-7351 guidelines.

3. All metal pads are to be non-solder mask defined (NSMD). Clearance between the solder mask and the metal pad is to be 60 µm

minimum, all the way around the pad.

4. A stainless steel, laser-cut and electro-polished stencil with trapezoidal walls should be used to assure good solder paste release.

5. The stencil thickness should be 0.125 mm (5 mils).

6. The ratio of stencil aperture to land pad size should be 1:1 for all perimeter pads.

7. A No-Clean, Type-3 solder paste is recommended.

8. The recommended card reflow profile is per the JEDEC/IPC J-STD-020 specification for Small Body Components.

EFM8BB1 Data Sheet

QSOP24 Package Specifications

silabs.com | Building a more connected world. Rev. 1.6 | 46

7.3 QSOP24 Package Marking

PPPPPPPP #

TTTTTTYYWW

EFM8

Figure 7.3. QSOP24 Package Marking

The package marking consists of:

• PPPPPPPP – The part number designation.

• TTTTTT – A trace or manufacturing code.

• YY – The last 2 digits of the assembly year.

• WW – The 2-digit workweek when the device was assembled.

• # – The device revision (A, B, etc.).

EFM8BB1 Data Sheet

QSOP24 Package Specifications

silabs.com | Building a more connected world. Rev. 1.6 | 47

2>< é».="" pin“="" \den'hfy:="" loser="" mark="" e="" \o="" coo="" c="" i="" r="" 4="" m="" —="" —="" ':'="" v_|_l="" |="" .="" i="" l="" m="" 2x="" "b”="" "="" "="" deta‘l:="" b="">‘\ = ( L K Baal

8. QFN20 Package Specifications

8.1 QFN20 Package Dimensions

Figure 8.1. QFN20 Package Drawing

Table 8.1. QFN20 Package Dimensions

Dimension Min Typ Max

A 0.70 0.75 0.80

A1 0.00 0.02 0.05

A3 0.20 REF

b 0.18 0.25 0.30

c 0.25 0.30 0.35

D 3.00 BSC

D2 1.6 1.70 1.80

e 0.50 BSC

E 3.00 BSC

EFM8BB1 Data Sheet

QFN20 Package Specifications

silabs.com | Building a more connected world. Rev. 1.6 | 48

Dimension Min Typ Max

E2 1.60 1.70 1.80

f 2.50 BSC

L 0.30 0.40 0.50

K 0.25 REF

R 0.09 0.125 0.15

aaa 0.15

bbb 0.10

ccc 0.10

ddd 0.05

eee 0.08

fff 0.10

Note:

1. All dimensions shown are in millimeters (mm) unless otherwise noted.

2. Dimensioning and Tolerancing per ANSI Y14.5M-1994.

3. The drawing complies with JEDEC MO-220.

4. Recommended card reflow profile is per the JEDEC/IPC J-STD-020 specification for Small Body Components.

EFM8BB1 Data Sheet

QFN20 Package Specifications

silabs.com | Building a more connected world. Rev. 1.6 | 49

Cl C3 4Y X3 + + + __ E + + Y2 f X1 Y1

8.2 QFN20 PCB Land Pattern

Figure 8.2. QFN20 PCB Land Pattern Drawing

Table 8.2. QFN20 PCB Land Pattern Dimensions

Dimension Min Max

C1 3.10

C2 3.10

C3 2.50

C4 2.50

E 0.50

X1 0.30

X2 0.25 0.35

X3 1.80

Y1 0.90

Y2 0.25 0.35

Y3 1.80

EFM8BB1 Data Sheet

QFN20 Package Specifications

silabs.com | Building a more connected world. Rev. 1.6 | 50

Dimension Min Max

Note:

1. All dimensions shown are in millimeters (mm) unless otherwise noted.

2. Dimensioning and Tolerancing is per the ANSI Y14.5M-1994 specification.

3. This Land Pattern Design is based on the IPC-7351 guidelines.

4. All metal pads are to be non-solder mask defined (NSMD). Clearance between the solder mask and the metal pad is to be 60 µm

minimum, all the way around the pad.

5. A stainless steel, laser-cut and electro-polished stencil with trapezoidal walls should be used to assure good solder paste release.

6. The stencil thickness should be 0.125 mm (5 mils).

7. The ratio of stencil aperture to land pad size should be 1:1 for the perimeter pads.

8. A 2 x 2 array of 0.75 mm openings on a 0.95 mm pitch should be used for the center pad to assure proper paste volume.

9. A No-Clean, Type-3 solder paste is recommended.

10. The recommended card reflow profile is per the JEDEC/IPC J-STD-020 specification for Small Body Components.

8.3 QFN20 Package Marking

PPPP

TTTTTT

YYWW #

Figure 8.3. QFN20 Package Marking

The package marking consists of:

• PPPPPPPP – The part number designation.

• TTTTTT – A trace or manufacturing code.

• YY – The last 2 digits of the assembly year.

• WW – The 2-digit workweek when the device was assembled.

• # – The device revision (A, B, etc.).

EFM8BB1 Data Sheet

QFN20 Package Specifications

silabs.com | Building a more connected world. Rev. 1.6 | 51

[ED 7 GAUGE 2X PLANE 4L, \_I_LUQ ”a C D 2x 8 TIPS PIN 1 LD‘ .1 L1“ k, DETAIL 'A' I-IME ,A Th x 45 [Ex- I ,ﬁi 74‘— SEATING .L;1T_' Ell-L1 ﬁPLANE SEE DETAIL 'A'J’

9. SOIC16 Package Specifications

9.1 SOIC16 Package Dimensions

Figure 9.1. SOIC16 Package Drawing

Table 9.1. SOIC16 Package Dimensions

Dimension Min Typ Max

A — — 1.75

A1 0.10 — 0.25

A2 1.25 — —

b 0.31 — 0.51

c 0.17 — 0.25

D 9.90 BSC

E 6.00 BSC

E1 3.90 BSC

e 1.27 BSC

L 0.40 — 1.27

EFM8BB1 Data Sheet

SOIC16 Package Specifications

silabs.com | Building a more connected world. Rev. 1.6 | 52

Dimension Min Typ Max

L2 0.25 BSC

h 0.25 — 0.50

θ 0º — 8º

aaa 0.10

bbb 0.20

ccc 0.10

ddd 0.25

Note:

1. All dimensions shown are in millimeters (mm) unless otherwise noted.

2. Dimensioning and Tolerancing per ANSI Y14.5M-1994.

3. This drawing conforms to the JEDEC Solid State Outline MS-012, Variation AC.

4. Recommended card reflow profile is per the JEDEC/IPC J-STD-020 specification for Small Body Components.

EFM8BB1 Data Sheet

SOIC16 Package Specifications

silabs.com | Building a more connected world. Rev. 1.6 | 53

E 7X1 LEEE r5333

9.2 SOIC16 PCB Land Pattern

Figure 9.2. SOIC16 PCB Land Pattern Drawing

Table 9.2. SOIC16 PCB Land Pattern Dimensions

Dimension Feature (mm)

C1 Pad Column Spacing 5.40

E Pad Row Pitch 1.27

X1 Pad Width 0.60

Y1 Pad Length 1.55

Note:

1. All dimensions shown are in millimeters (mm) unless otherwise noted.

2. This Land Pattern Design is based on IPC-7351 pattern SOIC127P600X165-16N for Density Level B (Median Land Protrusion).

3. All feature sizes shown are at Maximum Material Condition (MMC) and a card fabrication tolerance of 0.05 mm is assumed.

EFM8BB1 Data Sheet

SOIC16 Package Specifications

silabs.com | Building a more connected world. Rev. 1.6 | 54

9.3 SOIC16 Package Marking

PPPPPPPP #

TTTTTTYYWW

EFM8

Figure 9.3. SOIC16 Package Marking

The package marking consists of:

• PPPPPPPP – The part number designation.

• TTTTTT – A trace or manufacturing code.

• YY – The last 2 digits of the assembly year.

• WW – The 2-digit workweek when the device was assembled.

• # – The device revision (A, B, etc.).

EFM8BB1 Data Sheet

SOIC16 Package Specifications

silabs.com | Building a more connected world. Rev. 1.6 | 55

10. Revision History

10.1 Revision 1.6

March 13th, 2017

Updated the language in 1. Feature List to clarify the package offerings for each of the different temperature grades.

Corrected the application note number for AN124: Pin Sharing Techniques for the C2 Interface in 5.2 Debug.

10.2 Revision 1.5

October 7th, 2016

Added A-grade parts.

Added specifications for 4.1.13 SMBus.

Added bootloader pinout information to 3.10 Bootloader.

Added CRC Calculation Time to 4.1.4 Flash Memory.

Added Thermal Resistance (Junction to Case) for QFN20 packages to 4.2 Thermal Conditions.

Added a note linking to the Typical VOH and VOL Performance graphs in 4.1.12 Port I/O.

Added 4.1.10 1.8 V Internal LDO Voltage Regulator.

Added a note to 3.1 Introduction referencing the Reference Manual.

10.3 Revision 1.4

April 22nd, 2016

Added a reference to AN945: EFM8 Factory Bootloader User Guide in 3.10 Bootloader.

Added I-grade devices.

Added a note that all GPIO values are undefined when VDD is below 1 V to 4.1.1 Recommended Operating Conditions.

Adjusted the Total Current Sunk into Supply Pin and Total Current Sourced out of Ground Pin specifications in 4.3 Absolute Maximum

Ratings.

10.4 Revision 1.3

January 7th, 2016

Added 5.2 Debug.

Updated 3.10 Bootloader to include information about the bootloader implementation.

10.5 Revision 1.2

Updated Port I/O specifications in 4.1.12 Port I/O to include new VOL specifications.

Added a note to Table 4.3 Reset and Supply Monitor on page 18 regarding guaranteed operation.

Updated package diagram and landing diagram specifications for the QFN20 package.

10.6 Revision 1.1

Initial release.

EFM8BB1 Data Sheet

Revision History

silabs.com | Building a more connected world. Rev. 1.6 | 56

Q SILICON LABS

http://www.silabs.com

Silicon Laboratories Inc.

400 West Cesar Chavez

Austin, TX 78701

USA

Simplicity Studio

One-click access to MCU and

wireless tools, documentation,

software, source code libraries &

more. Available for Windows,

Mac and Linux!

IoT Portfolio

www.silabs.com/IoT

SW/HW

www.silabs.com/simplicity

Quality

www.silabs.com/quality

Support and Community

community.silabs.com

Disclaimer

Silicon Labs intends to provide customers with the latest, accurate, and in-depth documentation of all peripherals and modules available for system and software implementers using or

intending to use the Silicon Labs products. Characterization data, available modules and peripherals, memory sizes and memory addresses refer to each specific device, and "Typical"

parameters provided can and do vary in different applications. Application examples described herein are for illustrative purposes only. Silicon Labs reserves the right to make changes

without further notice and limitation to product information, specifications, and descriptions herein, and does not give warranties as to the accuracy or completeness of the included

information. Silicon Labs shall have no liability for the consequences of use of the information supplied herein. This document does not imply or express copyright licenses granted

hereunder to design or fabricate any integrated circuits. The products are not designed or authorized to be used within any Life Support System without the specific written consent of

Silicon Labs. A "Life Support System" is any product or system intended to support or sustain life and/or health, which, if it fails, can be reasonably expected to result in significant personal

injury or death. Silicon Labs products are not designed or authorized for military applications. Silicon Labs products shall under no circumstances be used in weapons of mass

destruction including (but not limited to) nuclear, biological or chemical weapons, or missiles capable of delivering such weapons.

Trademark Information

Silicon Laboratories Inc.® , Silicon Laboratories®, Silicon Labs®, SiLabs® and the Silicon Labs logo®, Bluegiga®, Bluegiga Logo®, Clockbuilder®, CMEMS®, DSPLL®, EFM®, EFM32®,

EFR, Ember®, Energy Micro, Energy Micro logo and combinations thereof, "the world’s most energy friendly microcontrollers", Ember®, EZLink®, EZRadio®, EZRadioPRO®,

Gecko®, ISOmodem®, Micrium, Precision32®, ProSLIC®, Simplicity Studio®, SiPHY®, Telegesis, the Telegesis Logo®, USBXpress®, Zentri and others are trademarks or registered

trademarks of Silicon Labs. ARM, CORTEX, Cortex-M3 and THUMB are trademarks or registered trademarks of ARM Holdings. Keil is a registered trademark of ARM Limited. All

other products or brand names mentioned herein are trademarks of their respective holders.

EFM8BB1 Datasheet by Silicon Labs

INFORMATION

HELP

CONTACT US

FOLLOW US
